Description
1. Rated :voltage 3.0V DC.
2. Operating voltage range: DC1.5-4.5V.
3. Operating temperature range: -10-65°C.
4. Environment temperature: 10-30°C.
And relative humidity： 30-95%.
5.No load speed: 45RPM±10%.
6.No load current: 0.055A (0.080A max).
7.Stall current: 1.2.A REF.
8.Stall torque: 2.0kg.cm(Min).
9.Shaft end play: <0.5 mm.
10.Shaft T.I.R :0.03mm(Max)at 2/3 of output shaft side and measured by dialgauge.
11.Mechanical noise: 75 DB(A) max mechanical noise under No-load at rated voltage.
Under rated voltage: (back ground noise to be 36db max).
Life end defined as follows:
